Example Models and Model Data

In this section, you will find a collection of different example models for ENVI-met (including associated .INX and .SIMX files plus other data) and simulated sample data from model simulations.

Please note:

  • Be aware that the sample model outputs can be huge in file size…
  • Some files have been simulated with Version 4.x. Some Variable names have been adjusted in V5, so Python scripts might need adjustment.


Dynamic Comfort: Columbus Circle Sample data set (INX File with Route, Atmosphere data) for the new Dynamic Thermal Comfort Module.
Data supplied: Model data and sample results Enter...


Urban Layout The Urban Layout model is a small (100 x 100 x 20 Grids) model that shows a simple urban scene including the use of receptors. Data supplied: Model data and Sample Results Enter...


German Foreign Embassy Berlin This example model file will come with the TreePass in the next release!




Improving Outdoor Thermal Comfort The Thermal Comfort Case Study is a small (200 x 190 x 30 Grids) model that was used to analyze minimal invasive climate adaptation strategies to mitigate urban excess heat. Enter...


Vegetation Vitality and Microclimate The Vegetation Case Study is a small (100 x 60 x 30 Grids) model that was used to analyze the influence of different microclimates onto the tree vitality. Enter...


Windflow in the City of Phoenix The Windflow Case Study is a complex (300 x 300 x 25 Grids) model that was used to analyze windflow within the city of Phoenix. Enter...


Solar Radiation and Access in Manhattan The Solar Radiation Case Study is a complex (1778 m x 1512 m x 784 m) model of Manhattan that was used to analyze solar access within the city. Enter...


Air Pollution: Simulating Ozone in an Urban Area The Air Pollution Case Study is a complex (2000 x 1200 x 90 m) model that was used analyze the concentration and distribution of O3 in an urban area. Enter...


Influence of Precipitation on Vegetation and Natural Surfaces The Precipitation Case Study is a small model that was used to analyze the influence of precipitation onto vegetation and natural surfaces. Enter...


Analysing Facade Materials This example is a small (50 x 50 x 30 Grids) model that was used analyze the different behaviors of a variety of façade materials. Enter...


Connecting Inside and Outside In the Connecting Inside & Outside Case Study, a small (40 x 40 x 30 Grids) model was used to analyze the different behaviors of a variety of façade materials and their influence on the building inside air temperature. Enter...


Heat Mitigation: Painting LA Streets White One adaption strategy to mitigate the Urban Heat Island effect is coating streets with a high albedo material to decrease surface temperatures of streets. In this case study, one of LA’s oldest neighborhoods, Angelino Heights, was simulated in order to analyze changes caused by different surface materials. Enter...


Soil Temperature The soil temperature model area is a small (47 x 39 x 25 Grids) model, which shows the impact on summer time microclimate of dry soils compared to sealed surfaces. Data supplied: Model data and Sample Results Enter...


to come… (empty) Enter...
